Advantages of CTP technology

1. High-precision, multi-resolution plate making

Each CRON machine simultaneously offers 4 different resolution levels (*see product specifications for details), expanding customer business competitive advantages.
Multi-resolution: 1800, 2400, 2540, 2800DPI
High resolution: 4800, 5080, 9600DPI
Lower resolution meets faster publishing speeds, while higher resolution caters to high-end printing and anti-counterfeiting needs, suitable for various frequency, amplitude, and new dot types, enhancing printing companies' business adaptability.

2. SMFO Patented laser technology

CRON CTP utilizes semiconductor laser technology and its proprietary SMFO technique for uniform laser output and superior imaging of optical square dots, ensuring better plate-making results and extended laser lifespan.
The single-channel array laser system perfectly addresses the uneven light path caused by individual laser attenuation in the light valve laser.
▪ Cost Savings: Lasers can be replaced individually or rearranged, significantly reducing maintenance costs of laser systems.
Test data shown that lasers lifespan could last 10,000 hours at 25°C and 40-60% humidity.

3. Optical drum vacuum constant pressure system

The optical drum is segmented for individual control. When not using the full sheet, the equipment seals off chambers to maintain safe vacuum pressure. This ensures stable pressure for all plate sizes, simplifying switching and boosting efficiency.

4. Advanced online punching system

Single positioning for exposure and punching, achieving ±10μm precision. No realignment needed, saving time and paper. Up to 5 sets of punch dies can be installed.

5. Fully automatic plate supply system

Comes with standard 50/100 sheet fully automatic plate supply system, upgradeable to 1500-sheet large capacity or 3/5 cassette systems, meeting multiple printing machines' automatic plate-making needs. Features innovative precise slip paper separation technology for high reliability.

6. Triple dynamic balancing technology

CRON's patented triple dynamic balancing technology automatically adjusts the position of balance blocks based on the plate material to achieve proper weight distribution. This ensures smooth engraving effects and prevents hardware damage due to vibration, safeguarding both plate-making quality and cost for customers.
It addresses issues such as non-full sheets, different thicknesses, materials, and sizes of plates, preventing changes in the drum's center of gravity and equipment shaking during high-speed rotation, which often leads to the problem of uneven horizontal and vertical lines.

7. Magnetic levitation linear scanning system

Advanced magnetic levitation linear scanning system, high speed, high precision, zero friction, maintenance-free. More precise motion control leads to superior plate-making results.

8. Dual hybrid constant temperature system

The laser box adopts a hybrid constant temperature system combining water cooling and air cooling, ensuring that the laser operates in an environment within ±0.5˚C. This extends the laser's lifespan and ensures more stable energy output.

9. Guide rail self-lubricating system

Classic fine-tuned V-shaped guide rail system, precise and wear-resistant, maintaining optimal constant focal length.
Automatic lubrication function, truly maintenance-free.
High-precision magnetic suspension linear motor drive, strong, smooth, and accurate, with axis-free suspension and no wear.

10. Multi-directional plate feeding

Inline punching and bridging. Supports four-way plate feeding and allows easy networking of multiple CTPs.

11. LaBoo remote service

The LaBoo system supports remote access to CRON's internet service support system, aiding in system diagnostics and swift troubleshooting.
Additionally, the LaBoo software's "dot compensation function" can rectify printing dot stretching resulting from rubber roller aging.

12. Precise 3-point positioning

Patented side pull gauge technology ensures precise 0.01mm repeat positioning, enabling easy alignment.
CRON CTP achieves high accuracy and stable image output, with dot restoration deviation within 1%. Calibration services standardize patching across different CTP models and years, streamlining prepress work for greater efficiency.
