LeiBa 26H fully automatic CTP

Compact and refined label making Plate-making area ranges from 240x240mm to 670x570mm, integrating automatic plate supply, laser imaging, and inline punching into one compact and refined unit, ideal for small-scale plate making applications like anti-counterfeit label printing.

Keyword:

automatic printing machine

Classification:

CTP

E-mail：

info@cron.com.cn

Return

Operation video

Customer Applications

Product Description

Product Parameters

Download information

Operation video

Customer Applications

Plate size: 240 x 240 mm ~ 670 x 570 mm
Models: 2624H / 2632H / 2648H / 2664H

CRON H series CTP integrates automatic plate supply, laser imaging, and inline punching into a compact unit, making it ideal for high-end printing, 3D printing, and anti-counterfeiting applications. The H series comes standard with a 50-sheet fully automatic plate supply mechanism and features innovative side-pull positioning and nozzle design for smooth plate feeding.

Product Introduction:

The LeiBa 26H fully automatic CTP is a prime example of a quality automatic printing machine, designed to streamline the pre-press process for printing operations. With its advanced features and robust construction, this automatic printing machine exporter’s product is suitable for a wide range of printing needs. The LeiBa 26H series, which includes models 2624H, 2632H, 2648H, and 2664H, supports plate sizes ranging from 240 x 240 mm to 670 x 570 mm, catering to various printing formats.

This quality automatic printing machine is equipped with a fully automatic plate supply mechanism that can handle up to 50 sheets, ensuring uninterrupted operation. The innovative side-pull positioning and nozzle design of the LeiBa 26H contribute to smooth and precise plate feeding, reducing the likelihood of errors and increasing overall efficiency. As an automatic printing machine exporter, we pride ourselves on delivering equipment that meets the highest standards of performance and reliability.

quality automatic printing machine

26H Commercial Series Specification

Model	2624H	2632H	2648H	2664H
Plate Size	Max.670x570mm / Min.240x240mm
Laser channel	24	32	48	64
Speed（Punch）	30(29) p/h 37(35)p/h 48(45)p/h 50(50) p/h 2400 dpi/510 mm
Speed（Punch）	25(24)p/h 31(30)p/h 41(39)p/h 49(46)p/h 2400 dpi/650 mm Production capacity in the table:TP ≤ 200 mj/cm² ，UVP-X+ ≤ 45 mj/cm² , UVP-I+ ≤ 55 mj/cm²
Plate Feeding Mode	Automatic
Plate Capacity	50 sheets
Paper Removal	Automatic
Power supply	Single-phase AC 220 V±5% 50/60 Hz Rated Power 5.3 KW
Dimensions	W×L×H: 1400×1055×1055 mm
Net weight	815kg
